Description
Experience unparalleled sonic precision with the ADAM Audio S5X-V, expertly crafted for medium to large control rooms and professional studios demanding exceptional sound pressure levels and dynamic range. This premium main monitor effortlessly delivers a detailed, natural, and spatially accurate audio reproduction that excels in critical mixing and mastering environments.
Main Features
- Handmade in Germany: combines X-ART Tweeter and proprietary X-ART Midrange driver for unmatched clarity
- Powerful 4-way system with 1 x 12" HexaCone woofer and 1 x 7.5" bass/midrange driver
- Amplifier power: 1250 W RMS (1750 W music) with dedicated 3-channel PWM amps (250 W each) plus a 500 W subwoofer amp
- Frequency response spanning 25 Hz to 50 kHz for full-range accuracy
- Maximum sound pressure level: ≥128 dB per pair at 1 metre distance
- Separate, acoustically optimised chambers for bass/midrange ensure clarity and transient precision
- Versatile vertical design for easy integration in multi-channel setups with consistent sound characteristics
The S5X-V features ADAM Audio’s exclusive X-ART midrange transducer, extending the precise treble clarity of the X-ART technology deep into the crucial midrange frequencies. The combination of the 12" woofer’s extended low-end capability and the 7.5" driver’s clarity provides an impressively rich and dynamic soundstage without overpowering bass. This controlled design prioritises accurate, balanced reproduction to enhance critical listening.
Multiple adjustable settings via the SX control panel enable you to finely tune the speaker to your room’s unique acoustics, ensuring repeatable, precise sound tailored to any control environment. Whether used individually or in multi-channel configurations, the S5X-V delivers consistent accuracy and high SPL performance.
Specifications
General Data
- Frequency Response: 25 Hz - 50 kHz
- THD 90 dB / 1 m > 100 Hz: ≤0.5 %
- Max. SPL with sine wave acoustic 100 Hz to 3 kHz at 1 m: ≥118 dB
- Max. SPL per pair at 1 m: ≥128 dB
- Crossover Frequencies: 160 / 800 / 4000 Hz
- Input Impedance: 10 kOhm
- Panel: Front
- Weight: 98.3 lb (44,6 kg)
- Magnetically Shielded: No
- Height x Width x Depth: 32.5" (830 mm) x 16" (410 mm) x 19" (480 mm)
Audio Input Connectors
- Analog: XLR
- Input Impedance: 48 kOhm
Amplification
- Woofer: 1
- Type: PWM
- Amp. Power RMS / Music: 500 W / 700 W
- Midrange (cone): 1
- Type: PWM
- Amp. Power RMS / Music: 250 W / 350 W
- Midrange: 1
- Type: PWM
- Amp. Power RMS / Music: 250 W / 350 W
- Tweeter: 1
- Type: PWM
- Amp. Power RMS / Music: 250 W / 350 W
Woofer
- Number: 1
- Basket Ø: 12" (305 mm)
- Voice Coil Ø: 3" (75 mm)
- Cone Material: HexaCone
Midrange (Cone)
- Number: 1
- Basket Ø: 7.5" (186 mm)
- Voice Coil Ø: 2" (50 mm)
- Cone Material: HexaCone
Midrange
- Number: 1
- Type: X-ART
- Diaphragm Area: 26 inch² (16800 mm²)
- Equiv. Diaphragm Ø: 5.5" (146 mm)
- Velocity Transform Ratio: 3.5:1
- Diaphragm Weight: 0.7 g
Tweeter
- Number: 1
- Type: X-ART
- Diaphragm Area: 4 inch² (2420 mm²)
- Equiv. Diaphragm Ø: 2" (56 mm)
- Velocity Transform Ratio: 4:1
- Diaphragm Weight: 0.17 g
Control Panel
- Input Sensitivity (coarse): -20 to +8 dB (4 dB steps)
- Input Sensitivity (fine): -1.5 to +2 dB (0.5 dB steps)
- EQ 80 Hz: 0 to +6 dB (1 dB steps)
- High Shelf EQ > 6 kHz: ±4 dB (1 dB steps)
- Low Shelf EQ < 150 Hz: ±4 dB (1 dB steps)
- Tweeter Gain: ±2 dB (0.5 dB steps)
Frequently Asked Questions
➤ What kind of rooms is the ADAM Audio S5X-V suited for?
The S5X-V is designed specifically for medium to large control rooms and professional studios where high SPL and precise acoustic reproduction are critical. It performs exceptionally well in environments that demand accuracy and dynamic range.
➤ What makes the X-ART midrange driver special?
The proprietary X-ART midrange driver extends the trademark clarity of ADAM’s X-ART tweeter into the mid frequencies, delivering exceptional transparency and detail in the crucial vocal and instrumental range. This results in remarkably natural and balanced sound reproduction.
➤ How powerful is the amplifier setup in the S5X-V?
The S5X-V features a total of 1250 W RMS amplifier power with a 3-channel PWM design: 250 W amplifiers for the tweeter, midrange, and bass/midrange drivers, plus a 500 W amplifier dedicated to the 12" HexaCone woofer delivering strong low-end support.
➤ Can the S5X-V be combined with other speakers in a multi-channel setup?
Yes, the vertical S5X-V maintains consistent sound characteristics that easily complement the horizontal S5X-H model and other ADAM Audio monitors, making it ideal for immersive multi-channel applications.
➤ How does the SX control panel improve usability?
The SX control panel offers an extensive range of precise controls that allow tailored tuning to your room’s acoustic properties. This ensures maximum adaptability and repeatable settings to suit various monitoring environments.
