RCF Evox 12 Active Two Way Array

Main Features

• 1400 Watt Peak, 700W RMS line array system
• 130 dB max SPL
• 40 Hz - 20 kHz frequency response
• 15 inch subwoofer / 8 x 4 inch neodymium full-range woofer
• 90° x 30° slightly tilted pattern control
• Innovative DSP processing
• Pole mountable, easy set-up and transportation

The RCF EVOX 12 is the most powerful line-source in its class and offers a particularly profound and dynamic reproduction at high levels due to the built-in 1400W power amplifier.


The EVOX 12's top section has eight high performance neodymium 4 inch full-range transducers with a phase plug. As a result, the EVOX 12 has a significantly increased low-mid playback at a constant level with a wide dispersion for the highs. The 15 inch subwoofer delivers powerful bass sound to reinforce a big party or the kick drum of a live band. Despite high performance, the enclosure is very compact, and thanks to integrated wheels and extendable handle, very easy to transport.


Acoustic Specifications
Frequency Response -3 dB: 40 Hz ÷ 20 Hz
Max SPL: 130 dB
Horizontal coverage angle: 90°
Vertical coverage angle: 30°
Full range: 8 x 4 inch, 1 inch v.c.
Woofer: 15 inch, 3 inch v.c.

Input/Output Section
Input connectors: Jack-XLR male
Output connectors: XLR female
Input sensitivity: -2 dBu / + 4 dBu

Processor Section
Crossover frequencies: 180 Hz
Protections: Thermal, RMS
Limiter: Soft limiter
Controls: Volume, EQ

Amplifier Specifications
Total power: 1400 W PEAK (HF 400W, LF 1000W)
Total power: 700 W RMS (HF 200W, 500W)
Cooling: Convection
Connections: VDE connector

Cabinet
Cabinet Material: Baltic birch plywood
Handles: 2 side, 1 top
Pole Mount/Cap: Yes
Colour: Black

Physical Specifications
Height: 2220 mm / 87.4 inch
Width: 410 mm / 16.14 inch
Depth: 560 mm / 22.05 inch
Weight: 36.4 kg / 80.24 lbs
